Koffee-King™ EXPLODED VIEW & PARTS LIST (continued)
19
M
611 75804
Owne
rs M
anual
Koffee-K
ing™ B
rewers
ITEM PART NO. DESCRIPTION
USED ON
1
8700-16
COVER PLATE, WARMER, BLACK
ALL
4
8543-80
CLIP, PANEL RETAINING
ALL
20
8543-23
NUT, #8SMS, TINNERMAN (not shown)
ALL
23
8543-69 BUSHING,
HEYCO
ALL
33
8543-42
GASKET, SPRAY HEAD
ALL
34
82727
SPRAY DISK, EMBOSSED
ALL
34a
8543-45
RETAINER, SPRAY HEAD (REQUIRES DRILL/RIVETS TO INSTALL)
ALL
35
85089
DOOR, SOLENOID ACCESS, PLASTIC
8540, -41, -72, -73, -74
38
8574-10
DOOR, ELECTRIC ACCESS
8574
40
8706-76
BUTTON PLUG, 1-1/8" DIA, METAL (WARMER PLATE RETAINER)
ALL (Canadian)
41
18-50
NUT, WARMER PLATE RETAINING, 1/4-28
ALL (Canadian)
47
8810-12
BUTTON PLUG, 1/2" DIA, PLASTIC (NON FAUCET MODELS)
8541, -42, -43, -71, -73
47a
8033-60
BUTTON PLUG, 3/8" DIA, METAL (HI-LIMIT RESET)
8574
48
81732
ASSEMBLY, ADJUSTABLE LEG
ALL
70
8706-75
BUTTON PLUG, 2" DIA, METAL (TIMER)
8540, -41, -71, -72, -73
101
8572-13
ASSEMBLY, BREWER TOP (BASIN)
ALL
102
8512-56
8542-6
BASIN COVER W/WARMER MOUNT
BASIN COVER, W/O WARMER MOUNT
8540, 8541, 8543
8542, -71, -72, -73, -74
103
86666
ASSEMBLY, POUR-OVER PLASTIC
ALL
108
8541-21
8543-29
BASIN PAN (AUTOMATIC)
BASIN PAN (POUR-OVER)
8540, -41, -72, -73, -74
8542, 8543, 8571
110
8542-110
8543-160
8541-160
8572-110
8571-20
LABEL, CONTROL PANEL DECAL (IN-LINE POUR-OVER 1W)
LABEL, CONTROL PANEL DECAL (IN-LINE POUR-OVER 2W)
LABEL, CONTROL PANEL DECAL (IN-LINE AUTOMATIC 2W)
LABEL, CONTROL PANEL DECAL (STEP-UP AUTOMATIC 3W)
LABEL, CONTROL PANEL DECAL (STEP-UP POUR-OVER 3W)
8542
8543
8540, 8541
8572, 8573, 8574
8571
111
8542-25
8540-25
8571-13
8572-33
(none)
ASSEMBLY, BREWER BASE (IN-LINE POUR-OVER)
ASSEMBLY, BREWER BASE (IN-LINE AUTOMATIC)
ASSEMBLY, BREWER BASE (STEP-UP POUR-OVER)
ASSEMBLY, BREWER BASE (STEP-UP AUTOMATIC)
ASSEMBLY, BREWER BASE (STEP-UP AUTOMATIC)
8542, 8543
8540, 8541
8571
8572, 8573
8574
112
8541-155
8543-48
8571-3
8572-10
PANEL, FRONT (IN-LINE AUTOMATIC)
PANEL, FRONT (IN-LINE POUR-OVER)
PANEL, FRONT (STEP-UP POUR-OVER)
PANEL, FRONT (STEP-UP AUTOMATIC)
8540, 8541
8542, 8543
8571
8572, 8573, 8574
114
8718-61
8549-26
8752-66
8571-19
PANEL, BOTTOM PLATE (IN-LINE)
PANEL, BOTTOM PLATE (IN-LINE W/ACCESS HOLE)
PANEL, BOTTOM PLATE (STEP-UP)
PANEL, BOTTOM PLATE (STEP-UP W/ACCESS HOLE)
IN-LINE (exc. Canadian)
IN-LINE (Canadian
STEP-UP (exc. Canadian)
STEP-UP (Canadian)
115
8572-16
PANEL, COVER W/WARMER MOUNT
8571, 8572, 8573, 8574
200
8942-6B
8942-6
8707-6
BREW CHAMBER, BLACK PLASTIC
BREW CHAMBER, BROWN PLASTIC (OPTIONAL limited to stock on hand)
BREW CHAMBER, STAINLESS W/ WIRE BASKET (OPTIONAL)
ALL
201
POF
FILTER PAPER, COFFEE (CASE OF 1000)
ALL
