C
C
C C
Figure 20.
MASONRY CHIMNEY
CLEAN OUT
DOOR
MASONRY
FLUE
LINERS
8"
Figure 19.
B. Rear exit into Masonry Flue using (6" DVL Close Clearance pipe).
With standard close clearance shield and pipe shield.
Model 261 minimum clearance to combustibles.
BACK WALL
A
E
B
F
D
G
A
E
B
F
BACK WALL
SIDE WALL PROTE
C
TO
R
D
A B C D E F G
MODEL 261 13”
13" 13" 16" 8" 3" 10"
CEILING
NEW BUCK
CAST COLLAR
Part# MA6CHIMCNB
NOTE: All clearances are to combustibles with all low clearance shields and Double wall
pipe , and minimum floor protector.NOTE: Floor protector must extend length of
horizontal flue pipe to wall. NOTE: Model 261 comes standard with low clearance shields.
G
8"
( NOTE: )
MINIMUM CLEARANCES FROM
TOP OF UNIT TO MANTEL OR
MANTEL SUPPORTS
“ 14 1/2
"
MINIMUM “
25
