OPERATION
225 Series 09/10 Operation Section 4-3
© 2010 Alamo Group Inc.
OPERA
T
ION
1. Standard Equipment and Specifications
Max. 2-Wheel Drive Tractor HP (PTO):
8’ 250 HP
10’ 225 HP
12’ 175 HP
Max. Front Wheel Assist Tractor (PTO):
8’ 225 HP
10’ 200 HP
12’ 160 HP
Moldboard Width 8’, 10’, 12’
Moldboard Dimension 1/2” x 20”
Cutting Edge 1/2” x 6”
Support Stand Standard
Hitch CAT II-III and QH
King Pin Diameter 4-1/2”
Adjustment Types Hydraulic
Offset (Maximum Left or Right) 46”
Pivot:
Forward Angle Up to 45°
Reverse Angle Up to 45°
Tilt (Up and Down) Up to 15°
Weight (Approx.):
8’ 2120 lbs.
10’ 2260 lbs.
12’ 2400 lbs.
