Bush Hog TOUGH 35 - Manual

Bush Hog
®
TOUGH
35 & 50 Rear Mounted Blades
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Page 44
35 Series Blade
50 Series Blade
BUSH HOG ® TOUGH FeaTUReS
TOUGH Tubular Construction
TOUGH a Frame Construction
TOUGH Double Strap Hitch (50 Series)
TOUGH Reversible Cutting edge
TOUGH Powder Coat Paint
MODelS 35 50
Moldboard Widths 4, 5, 6 and 7 ft 6 and 7 ft
approximate Weight 250 lbs (4 ft), 280 lbs (5 ft), 390 lbs (6 ft),
290 lbs (6 ft), 325 lbs (7 ft) 455 lbs (7 ft)
Maximum Tractor HP 35 PTO (2WD); 30 PTO (4WD) 50 PTO (2WD); 40 PTO (4WD)
Type Hitch 3 Point Category I & Quick Hitch 3 Point Category I & Quick Hitch
Moldboard Height and Thickness 14.5 inches x 1/4 inches 16 inches x 5/16 inches
Moldboard Cutting edge 1/2 x 6 inches, Reversible 1/2 x 6 inches, Reversible
King Pin Diameter 1 1/4 inches (Grade 8) 1 1/4 inches (Grade 8)
Tilt adjustment 15° Up or Down 15° Up or Down
Offset adjustment 12 inches Left or Right 23 inches Left or Right
angle adjustment 5 Forward Positions up to 30°, 3 Reverse Positions up to 15°
Blade Parking Stand Standard Standard
Warranty 1 year limited warranty
FeaTUReS • Available in major tractor colors
