Bunn LCR-3 HV User Manual
High volume liquid coffee refrigerated dispenser, Features related products, A6.6

Features
Related Products
Item#
Project
Date
For current specification sheets and other information, go to www.bunn.com.
Patents Apply
9/08
A6.6
Model
Agency Listing
Lcr-3, HV
High Volume Liquid Coffee
Refrigerated Dispenser
Model LCR-3 HV
Dimensions: 40” H x 33” W x 23.6” D
(101.6 cm H x 83.8 cm W x 59.9 cm D)
Easy Clear
®
EQHP-54
Product No. : 39000.0006
Easy Clear
®
EQHP-54L
Product No. : 39000.0003
Easy Clear
®
EDSS-11-T200F
System
Product No. : 30370.1000
Easy Clear
®
EDSS-11-T200F
Cartridge
Product No. : 30370.1001
Scholle BIB connector
Product No. : 35057.0000
250ml Graduated Cylinder
Product No. : 34028.0000
For use in calibration of pumps.
LiquiBox QC/D II
BIB connector
Product No. : 35055.0000
Liquid Coffee Refrigerated Dispenser
High volume Coffee-On-Demand dispenser meets the requirements
of banquet halls, convention centers, stadiums and hotels
• Refrigerated product cabinet extends product flavor profile, adjustable to maintain
41º to 65ºF in the product compartment.
• LCD screen for programming and user interface.
• Holds up to three 1-gallon BIB’s.
• Delivers 6 oz. per second of hot coffee on demand, 30-145 gallons of coffee per
hour (varies by voltage and incoming water temperature).
• 3-phase or single phase operation.
• Optional “Auto-Switching” function automatically switches from an empty BIB to a
secondary BIB (left and middle pump only).
• Choose from 3 portion sizes via rotary selection switch.
• 18 gallon (82L) tank capacity.
• Manual hot water faucet.
• Sanitation listed by NSF Standard 18 and safety listed by UL Standard (UL 197).
BIB compartment view
