Figure 3 - HLX Arrangement
6
AIR
DIAL
SETTING
Stop Screw
AFII 85
AFII 100
AFII 150
0
0.40-0.65 0.50-0.65 0.75-1.00
1
-
0.60-0.75
0.85-1.10
2 -
0.65-0.80
0.95-1.15
3
0.60-0.75
0.65-0.90
0.95-1.20
4 -
0.75-0.95
1.10-1.25
5
0.70-0.85
0.85-1.00
1.15-1.35
6 -
0.95-1.10
1.15-1.40
7
-
-
1.25-1.50
8 - -
1.30-1.50
Firing Rate at
140 psig
AFII 85
AFII 100
AFII 150
0.40 to 0.65
3
-
-
0.60 to 0.75
4
3
-
0.70 to 0.85
5
4
-
0.75 to 1.00
-
5
2
0.95 to 1.20
-
-
3
1.15 to 1.35
-
-
4
1.25 to 1.50
-
-
5
FIRING
RATE
Prepare burner & site
SK9644A
