Fig. 27 — internal control panel – Bryant 619FNQ User Manual
Page 18
—18—
INTERNAL CONTROL PANEL
619FNF018
Capacitor
GMC board
Electric heater board
(only on models with electric heater)
Transformer
Holes for fixing panel in position
Emergency push-button
Fan connector
LED/RECEIVER connector
Float connector
Pump connector
Louver connector
C
P
C
G
C
A
C
V
C
LR
INTERNAL CONTROL PANEL
619FNF024, 03036
619FNQ01824, 03036
CA
CLR
CV
C G
CP
CV
CP
CG
CA
CLR
Fig. 27 — Internal Control Panel
