SEPTEMBER 6, 2001 7 MT2136 E & G
EXTERIOR COMPONENTS
Ref. Part
No. No. Description
M2085Decal, Control Panel, SB, Red
M2087 Decal, Control Panel, TB, Red
7 M4306 Crumb Pan, Idle (Remote & Integral)
3 M4372 Crumb Pan, Drive w/ Remote
M4305Crumb Pan, Drive w/ Integral
M4309 Stop, Product
6 M7002 Extension Assy., Product 6"
M6997 Extension Assy., Product 12"
M2059 Drip Pan (Aluminized)
M5008 Drip Pan (S/S)
M2450 Access Panel, Combustion Compartment
(Manual)
M3376 Access Panel, Combustion Compartment
(Computer Controls)
M3553 Access Panel, Control Box (Integral)
13 M6389 Access Panel, Entire Front, Solid
(Has no opening for Sandwich Door)
13 M4580 Access Panel, Entire Front
(Has opening for Sandwich Door)
M6970 Access Panel Conversion Kit
(To add a Solid Sandwich Door)
M9217 Access Panel Conversion Kit
(To add a Glass Sandwich Door)
M10181 Sandwich Door Assy, 17"x 5", Solid w/handle
Replaces M4587
M10243 Sandwich Door Assy, 17"x 5",Glass w/handle
Replaces M9237
NOTE: For ALL ovens, if you need a new sandwich
door order part M10181, Door Assy,
Sandwich Solid w/handle or part M10243,
Door Assy, Sandwich Glass w/handle.
M10128 Handle Kit, 16 1/2" For M10181 & M10243
For ovens after 12/05/00 or converted units
with 16 1/2" handle
M2188 Handle Assy, black plastic, for Sandwich
Door 2" Handle For ovens before 12/05/00
NOTE: To convert from 2" to 16 1/2" Handle, you
must purchase complete Sandwich Door
Assy M10181 or M10243.
M6035Latch, Sandwich Door
M4581 Plate, Pivot RH Slotted
M4582 Plate, Pivot LH Slotted
M2514 Bolt, Front Access Panel
(Allen Head Decoration)
M2515 Allen Key for M2514
M9768 Gasket Assy, Front Access Panel
(Replaces M2599 & M3420)
M2801 Hinge Pin & Plate Assy.
16470 Nameplate, Blodgett 10"
21826 Installation Hose, 36"
21242 Installation Hose, 48"
EXTERIOR COMPONENTS-CONT'D.
Ref. Part
No. No. Description
21 M7273 Body Top w/ Hardware
M2678 Body Back
M2532 Triple Stacking Base w/ Casters
M9106 Pin, Stacking (Set of 4)
M2439 Stand, 24" w/Caster Assy.
M9481 Stacking Kit, ZA/ZA Manual Controls
M9482 Stacking Kit, ZA/ZA Integral Controls
M9483 Stacking Kit, AA/AA Remote Controls
M9486 Stacking Kit, AB/ZA or AA Integral Controls
M9487 Stacking Kit, AB/ZA or AA Remote
Controls
M6846 Chimney Kit, Sgl
M6847 Chimney Kit, Dbl
M6848 Chimney Kit, Tpl
M3998 Heat Shield Kit
1 M2075Tunnel Extension Cover & Clip Assy.
M9932 Kit, Integral to Remote Mount, Computer
Conversion
