—8—
SMART HEAT
* Field convertible to 1 phase.
† KFAEH2501N09 is field convertible to 3 phase.
‡ Single point wiring kit required for these heaters in Canada.
** Blower motor heat not included.
When using units with 20-, 24-, and 30-kw electric heaters, maintain a 1-in. clearance from combustible materials to discharge plenum and ductwork,
and maintain a distance of 36 in. from the unit. Use an accessory downflow base to maintain proper clearance on downflow installations.
Use flexible connectors between ductwork and unit to prevent transmission of vibration. When electric heater is installed, use heat resistant material
for flexible connector between ductwork and unit at discharge connection. Ductwork passing through unconditioned space must be insulated and
covered with vapor barrier.
ESTIMATED SOUND POWER LEVEL (dBA)
* Estimated sound power levels have been derived using the method described in the
1987 ASHRAE HVAC Systems & Applications Handbook,
Chapter 52, p. 52.7
HEATER
PART NO.
KW
@ 240V
VOLTS/PHASE
STAGES
(KW OPERATING)
INTERNAL
CIRCUIT
PROTECTION
FAN COIL SIZE
USED WITH
HEATING CAP. **
@ 230V
KFCEH0101H10
10
230/1
3, 6, 9
None‡
001, 002
31,400
KFCEH0201H15
15
230/1
3, 8, 11, 15
Fuse
001–003
47,100
KFCEH0301H20
20
230/1
5, 10, 15, 20
Fuse
002–004
62,800
UNIT
SIZE
CONDITIONS
OCTAVE BAND CENTER FREQUENCY*
CFM
Ext Static
Pressure
63
125
250
500
1000
2000
4000
FH4-001
800
0.25
66.0
62.0
58.0
55.0
53.0
51.0
47.0
FH4-002
1200
0.25
67.8
63.8
59.8
56.8
54.8
52.8
48.8
FH4-003
1600
0.25
69.0
65.0
61.0
58.0
56.0
54.0
50.0
FH4-004
2000
0.25
70.0
66.0
62.0
59.0
57.0
55.0
51.0
