—6—
SPECIFICATIONS
AIRFLOW PERFORMANCE* (CFM)
* With factory approved filter, 10-kw elec heat 001 and 002 sizes, 15-kw elec heat 003 and 004 sizes 230-volt.
AIRFLOW PERFORMANCE WITH ACCESSORY COIL (CFM)
NOTES: 1. Airflow based upon dry coil at 230v with factory approved accessory filter and electric heater (10-kw electric heat, sizes 001 and 002;
15-kw electric heat, sizes 003 and 004).
2. To avoid potential for condensate blowing out of drain pan prior to making drain trap:
—Return static pressure must be less than 0.4 in. wc
—Horizontal applications of 048-070 sizes must have supply static greater than 0.20 in. wc
Airflow outside max ARI airflow of 450 cfm/ton on 018-154 sizes
Airflow above 400 cfm/ton on 060-070 sizes. Airflows in this region could result in condensate blowing off coil or splashing out of drain pan.
FILTER STATIC PRESSURE DROP (IN. WC)
UNIT SIZE 001 002 003 004
FAN
Air Discharge
CFM (Nominal)
Motor Hp (PSC)
850
1/4
1300
1/3
1700
3/4
2000
3/4
FILTER 21-1/2 x 13 21-1/2 x 16-3/8 21-1/2 x 19-7/8
SIZE
BLOWER
SPEED
EXTERNAL STATIC PRESSURE (IN. WC)
0.10 0.20 0.30 0.40 0.50 0.60
208 230 208 230 208 230 208 230 208 230 208 230
FH4B001
HIGH 1173 1270 1135 1225 1090 1170 1045 1126 993 1058 925 981
MED 900 1025 875 991 847 963 810 922 768 869 695 802
LOW 579 687 560 663 537 639 505 610 451 554 384 467
FH4B002
HIGH 1630 1841 1605 1798 1567 1748 1525 1696 1480 1629 1415 1560
MED 1244 1438 1225 1407 1190 1383 1170 1342 1141 1308 1100 1265
LOW 1001 1172 985 1147 955 1116 930 1094 908 1062 850 1024
FH4B003
HIGH — — — — 2118 — 2060 2202 1949 2106 1853 1989
MED 1757 2061 1745 2016 1734 1985 1716 1943 1686 1890 1624 1802
LOW 1290 1535 1286 1535 1281 1528 1277 1515 1263 1467 1245 1431
FH4B004
HIGH — — — — 2257 — 2235 — 2188 — 2113 2336
MED — — 1930 2215 1914 2196 1887 2163 1838 2106 1787 2047
LOW 1620 1881 1620 1870 1613 1864 1607 1853 1594 1836 1562 1802
MODEL
AND
SIZE
BLOWER
MOTOR
SPEED
TOTAL EXTERNAL STATIC PRESSURE (IN. WC)
0.10 0.20 0.30 0.40 0.50 0.60
208 230 208 230 208 230 208 230 208 230 208 230
FH4B001 WITH
KFAEC0501024
HIGH 945 975 900 930 840 870 780 805 695 725 560 595
MED 835 900 795 855 745 800 690 740 610 650 470 510
LOW 605 695 575 665 530 625 485 580 425 510 340 395
FH4B002 WITH
KFAEC0601036
HIGH 1485 1550 1425 1490 1365 1420 1300 1350 1230 1275 1150 1190
MED 1235 1380 1200 1325 1160 1265 1110 1210 1055 1140 985 1070
LOW 1035 1185 1010 1150 980 1115 940 1070 890 1010 825 935
FH4B003 WITH
KFAEC0301048
HIGH 1880 1935 1785 1830 1700 1735 1615 1645 1520 1555 1430 1460
MED 1740 1840 1660 1750 1585 1660 1510 1575 1435 1485 1350 1390
LOW 1425 1605 1395 1555 1360 1495 1315 1430 1255 1360 1170 1270
FH4B004 WITH
KFAEC0401060
HIGH 2145 2245 2085 2185 2030 2115 1965 2045 1905 1975 1830 1895
MED 2025 2175 1970 2110 1915 2050 1860 1990 1805 1905 1740 1830
LOW 1680 1895 1655 1855 1625 1810 1595 1765 1555 1705 1500 1645
UNIT SIZE
CFM
400 600 800 1000 1200 1400 1600 1800 2000
001 — 0.044 0.075 0.110 — — — — —
002 — — — 0.072 0.100 0.130 — — —
003 — — — — — 0.092 0.120 0.152 —
004 — — — — — — 0.120 0.152 0.187
