Bolens 12226 - Manual (Page 25)

Parts List 25
Model 12226
REF PART
No. No. DESCRIPTION QTY.
REF PART
No. No. DESCRIPTION QTY.
1 1918219 Handlebars–(Incl. Refs. 2, 3 and 3A)... 1
2 9126 Grip ..................................................... 2
3 1918218 Decal–Wheel Engage ........................... 1
3A 1918334 Decal–Logo ......................................... 1
4 1916928 Decal–Bail Drive................................... 2
5 1186347 Height Adjustment Flange Screw ........ 1
5A 9955 Keyed Washer...................................... 1
6 1900475001 Bracket–Handlebar height adjust ......... 1
7 1100046 Hex Hd. Screw, 3/8-16 x 1*................. 2
8 9904 Plain Washer (flat), 3/8, S.A.E. ............ 2
9 9837 Hex Locknut, 3/8-16 ............................ 2
10 1918791 Cable, Forward Clutch Control ............. 1
13 9442 Wheel Gear Control & Cable Assy.
(Incl. Refs. 14, 15, 19, 21,
22 and 23) .......................................
1
14 9057 Knob–Wheel gear control lever............ 1
15 1186211 Hex Nut, 5/16-24 – Wheel gear
cable adjustment.............................. 2
16 1100068 Hex Hd. Screw, 3/8-16 x 3/4*.............. 2
17 1100243 Lockwasher, 3/8 .................................. 2
19 1735531 Plastic Tie ............................................ 2
21 1114748 Round Hd. Screw, #10-32 x 1/2 .......... 6
22 1100240 Lockwasher, #10 ................................. 2
23 1186208 Hex Nut, #10-32 .................................. 2
24 9390 Grip–Lever........................................... 2
25 1918840 Lever–Forward Clutch Control (Incl.
two Grips, Ref. 24) .......................... 1
35 9853 Sems Nut............................................. 4
36 20806 Bracket–Bail support ........................... 2
42 1100805 Hex Flange Screw, self-tapping,
1/4-20 x 1/2* ................................... 2
* Specify GRADE 5 if ordering part locally.
PARTS LIST - DRAWING NO. 1
