OPTIONAL PARTS
7
For Models: RBS245PRB02, RBS245PRQ02, RBS245PRT02, RBS245PRS02
(Black) (Designer White) (Biscuit) (Stainless)
W10208654
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242827 Wire (14 Ga.
150 c Yellow)
WIRING HARNESS PARTS
4449809 Screw
8301400 Harness, Main
4451761 Support, Wiring
4454842 Tie, Cable
4450952 Conduit
4450800 Screw, Ground
4448664 Clamp
98997 Clip
7103P027−66 Nut, Terminal
Block
4449809 Screw
4452400 Lead, Ground Strap
4454835 Tie, Cable
Miscellaneous
W10106920 Screw, Install
