OVEN PARTS
2
For Models: RBS245PRB02, RBS245PRQ02, RBS245PRT02, RBS245PRS02
(Black) (Designer White) (Biscuit) (Stainless)
W10208654
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
8303871 Installation
Instructions
W10162170 Use & Care Guide
8301758 Tech Sheet
8304571 Installation/
Undercounter
8301928 Installation/
MWO Trim Kit
9762761 Safer Cooking Tips
2 Trim, Side
Right
W10136093 Black
W10136094 White
W10136096 Biscuit
Left
W10136092 Black
W10136095 White
W10136097 Biscuit
3 Hinge Receiver
4455606 Right
4455605 Left
4 W10105790 Bumper, Door
5
Screw
3400832 Black
3400805 Zinc
7 4455863 Top Chassis
8 4448444 Grommet, Mounting
Rail
9 4452158 Tube, Vent
3196176 Screw
10 W10067870 Lens, Light
11 W10009930 Assembly, Oven
Light
12 4452166 Bulb, Light
14 9760754 Frame, Front
15 4455380 Gasket, Door
16 4449809 Screw
17 4449040 Screw
18 4452152 Bracket, Mounting
Bottom Vent
19 4451476 Support, Insulation
4449154 Screw
21 Rail, Side
8303115 Right
8303116 Left
22 9760888 Latch, Motorized
23 4449154 Screw
25 4455641 Side, Chassis
26 4452232 Back, Chassis
27 Liner, Oven
(Not serviceable)
29 W10131825 Sensor
33
9760675 Deflector, Vent
37 9759243 Thermostat
38 4450525 Base, Chassis
39 4448933 Retainer,Gasket
40 4451747 Cover, Back
41 Trim, Bottom
8303575 Black
8303576 White
8303577 Biscuit
42 4449845 Support, Bracket
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449314 Insulation, Wrap
4450363 Insulation, Back
