Jenn-air, Detailed planning dimensions, 48"/36" custom hood liners
Product dimension, cutout and installation specifications are provided for planning purposes only. Before installing
any product, be sure to verify cutout dimensions and electrical/gas connections as actual product dimensions may vary.
JENN-AIR
®
DETAILED PLANNING DIMENSIONS
1 of 4
JRC120072A 07/2012
48"/36" CUSTOM HOOD LINERS
UXL6048YSS – 47
7
⁄
8
" x 11
1
⁄
2
" x 22"
UXL6036YSS – 35
7
⁄
8
" x 11
1
⁄
2
" x 22"
PRODUCT DIMENSIONS
FRONT VIEW
MODEL #
UXL6048YSS
UXL6036YSS
in
cm
in
cm
A
Width of upper portion
of hood liner
27
5
⁄
8
70.1
27
5
⁄
8
70.1
B
Overall width
47
7
⁄
8
121.6
35
7
⁄
8
91.1
C
Height from hood liner
to hood support
5
1
⁄
8
12.8
5
1
⁄
8
12.8
D
Overall height
11
1
⁄
2
29.2
11
1
⁄
2
29.2
E
Depth of upper portion
of hood liner
12
3
⁄
8
31.4
12
3
⁄
8
31.4
F
Overall depth
22
55.9
22
55.9
G
Vent collar diameter
10
25.4
10
25.4
A
C
D
E
F
B
F
B
G
SIDE VIEW
TOp VIEW
A
C
D
E
F
B
F
B
G
A
C
D
E
F
B
F
B
G
