243L NONSLIP
AB CRUNCH STRAP
SINGLE HANDLE
ANKLE STRAP
LINK
CLIP
SEAT PAD
BACK PAD
FOAM PAD
COVER OF FOAM PAD (all pre-assembled)
1-1/4" X 430mm HAND GRIP
1" X 200mm ROUND HAND GRIP
1" X 95mm HAND GRIP (all pre-assembled)
LAT BAR HOLDER COVER
(all pre-assembled)
1-1/4" X 140mm ROUND HAND GRIP
1-1/4" HAND GRIP (all pre-assembled)
1" X 70mm HAND GRIP (all pre-assembled)
CABLE ARM STOPPER (all pre-assembled)
BEARING BASIN (all pre-assembled)
BEARING (all pre-assembled)
BEARING COVER (all pre-assembled)
SEALING RING (all pre-assembled)
1" T SHAPE END PLUG
(all pre-assembled)
114mm PULLEY
90mm PULLEY
50 X 75mm RECT. END CAP
50mm SQ. END CAP
25 X 50mm RECT. END CAP
40 X 80mm OVAL PLUG
1-1/4" ROUND END PLUG
PLASTIC COVER
PLASTIC WASHER
1" ID PLASTIC GUIDE ROD HOLDER
1" ID STEEL BUSHING (all pre-assembled)
3/4" ID BUSHING (all pre-assembled)
5/8" ID BUSHING (all pre-assembled)
3/8" ID BUSHING
LEG EXTENSION BEARING
RUBBER CUSHION
1/2" STOPPER (all pre-assembled)
PRESS ARM STOPPER
(all pre-assembled)
SEAT PAD SUPPORT STOPPER
(all pre-assembled)
RUBBER STOPPER (all pre-assembled)
LOCKING SPRING KNOB
LONGER RED POP PIN
SHORTER RED POP PIN
TOP CABLE
AB CRUNCH CABLE
LOWER CABLE
CONNECT CABLE
CABLE ARM CABLE
CLUTCH CABLE
CLUTCH LEVER OF CABLE ARM
SELECTOR PIN
PARTS LIST
NO. DESCRIPTION QTY.
