Bunn CWT-TS - Manual (Page 5)

Page 5
10165.0000D 6/93
© 1988 BUNN-O-MATIC CORPORATION
BE SURE TO INSTALL THE ABOVE
ASSEMBLY AS SHOWN
Models CWT-APS, CWT-TS
1.
Attach the flare fitting from the short piece of
tubing on the flow control (supplied) to the
water inlet fitting at the left rear of the brewer.
2. Flush the water line and securely attach it to the
flare fitting on the strainer.
3. Turn on the water supply.
Models CWTF-APS, CWTF-TS:
1.
Attach the flare fitting from the short piece of
tubing on the flow control (supplied) to the
lower water inlet fitting at the left rear of the
brewer.
2. Attach the flare fitting from the short piece of
tubing on the needle valve or tee (supplied) to
the upper water inlet fitting at the left rear side of
the brewer.
3. Flush the water line and securely attach it to the
flare fitting on the strainer or tee.
4. Turn on the water supply.
5. Place an empty vessel beneath the faucet and lift
the handle until water is dispensed.
BE SURE TO INSTALL THE ABOVE
ASSEMBLY AS SHOWN
26225.0000A 4/95 © 1995 BUNN-O-MATIC CORPORATION
FLOW
BE SURE TO INSTALL THE ABOVE
ASSEMBLY AS SHOWN
10447.0000C 6/93 © 1989 BUNN-O-MATIC CORPORATION
FIRST TYPE MODELS W/FAUCET
PLUMBING REQUIREMENTS (cont.)
EARLY MODELS W/OUT FAUCET
SECOND TYPE MODELS W/FAUCET
