21
Venice_Care+Maint.fm 1/07
C ARE AND M AINTENANCE
English Deutsch Français Dansk Español Italiano Svenska Nederlands Dansk Italiano Svenska Deutsch Nederlands English Français Español
Limited Warranty and Registration
Your product is covered by a limited transferable warranty. Details of the warranty are
provided with your product. Register your products online at www.Bose.com/register or
call (800) 905-1044. Failure to do so will not affect your warranty rights.
Accessories
Visit www.Bose.com/musicians, or call (800) 905-0886 for accessory information.
Technical Information
Mechanical
Electrical
• AC power rating:
100-120V 50/60Hz 500W (USA/Canada); 220-240V 50
/60Hz 500W (Europe)
• Peak inrush current:
32A @ 120V 60Hz (USA/Canada); 61A @ 230V 50Hz (Europe)
Audio Input/Output
• T1 ToneMatch TM port: DC output/data input Ethercon/RJ45 connector for a
T1 ToneMatch audio engine
• Analog Input: Line-level input channel for ¼" TRS phone plug
• Bass - Line Out: -4dBu (nominal), +9dBu (max.) (balanced TRS connection)
-10dBu (nominal), +3dBu (max.) (unbalanced TS connection)
• Bass Module Out: Neutrik NL4 output for one or two B1 bass modules
Dimensions Weight
L1 TM model II power stand: 5 ''H x 10''W x 27''D
(12.8 cm x 26.2 cm x 69.2 cm)
23.7 lb
(10.7 kg)
L1 model II Cylindrical Radiator ®
loudspeaker top:
43½ ''H x 3½''W x 4''D
(11.1 cm x 9.0 cm x 10.5 cm)
16.3 lb
(7.4 kg)
L1 model II Cylindrical Radiator ®
loudspeaker bottom:
43½ ''H x 3½''W x 4''D
(11.1 cm x 9.0 cm x 10.5 cm)
17.4 lb
(7.9 kg)
B1 bass module: 15 ''H x 10¼''W x 17¾''D
(38.0 cm x 26.0 cm x 45.0 cm)
25.1 lb
(11.4 kg)
Impedance
L1 TM model II Cylindrical
Radiator ® loudspeaker: 4
Ω
B1 bass module: 8
Ω
