2-6 User’s Manual
The Grand Tour
Front with the display open
The following figure shows the front of the computer with the display open.
To open the display, slide the display latch on the front of the display and lift
up. Position the display at a comfortable viewing angle.
The front with the display open
1.DC-IN LED
2.Power LED
3.Battery LED
4.Hard Disk LED
5.Multiple Digital Media Card Access LED
6.Display Screen
7.Power Button 8.Internet Button
9.CD/DVD Button
10.Play/Pause
11.Stop
12.Previous
13.Next
14.TouchPad
15.TouchPad Controls
n o p q r
s
t
u
v
w
z
11
z
12
z
13
z
14
z
15
DC IN LED The DC IN LED indicates the computer is
connected to the AC adapter and it is plugged
into an AC power source.
Power LED The Power LED flashes amber while the system
is in Standby mode. The LED turns off when the
computer is turned off or in hibernation mode.
In normal operating mode, the LED is green.
