2-4 User’s Manual
The Grand Tour
Back side
The following figure shows the computer's back panel.
The back side of the computer
1.Security Lock
2.Universal Serial Bus (USB) Port
3.RGB (Monitor) Port
4.TV Out Port 5.DC IN 19V Jack
6.Fan Vent
7.LAN Jack
t r o p q s n
Security Lock A security cable attaches to this port in order to
anchor your computer to a desk or other large
object to deter theft.
Universal Serial Bus
(USB) Ports
The Universal Serial Bus (USB 2.0 and 1.1) ports
enable USB-equipped devices (such as
keyboards, mice, hard drives, scanners,
and printers) to be connected to the computer.
RGB (Monitor) Port This 15-pin port lets you connect an external
video display to the computer.
TV Out Port Plug a 4-pin S- video cable into this connector for
the output of an NTSC or PAL signal.
DC IN 19V Jack The DC IN jack is where you plug in the AC
adapter.
Fan Vents The fan vents help to keep the CPU from
overheating.
LAN Jack This jack lets you connect to a LAN.
The adapter has built-in support for Ethernet
LAN (10 megabits per second, 10BASE-T),
Fast Ethernet LAN (100 megabits per second,
100BASE-TX) or Gigabit Ethernet LAN
(1000 megabits per second, 1000BASE-T).
Two indicators built into the jack let you see the
LAN status.
To prevent possible over heating of the CPU, never block the fan vents.
