Setting up the sewing computer 18
Stitch plate
Stitch plate markings
•
the stitch plate is marked with seam guide lines in mm and inches
• the millimetre markings are at the front
• the inch markings are at the back
• the measurements show the distance (with needle position centre) from
needle to line
• lines are provided to the right and left of the needle
•
they are very useful guide lines for precise seaming
•
the horizontal lines are useful for sewing corners, etc.
Feed-dog
Button below the handwheel
Button flush with housing =
sewing position
Button depressed = feed-dog is lowered
•
for free-hand sewing (darning, embroidery, etc.)
1 5/8 1
10 20 10 20
1/4 1/4 5/8
