Bernina Sewing Machine - Manual (Page 15)

15 Setting up the sewing computer
Changing the presser foot
Changing the presser foot
sole
• raise the needle and the
presser foot shaft
•
turn power switch to «0»
•
press the button on the shaft
to release the sole
Attaching the presser foot
sole
• place the presser foot sole
under the shaft so that the
peg sits under the opening of
the shaft
Refer to the safety
instruction!
Collapsible vertical spool pin
• found on the back of the sewing computer
behind the handwheel
•
essential aid for sewing with more than one thread, i.e. double
needle work
•
raise the pin until it clicks into its vertical position
• when using large reels, add the foam pad A for stability
Supplementary spool pin
A
• lower the presser foot lifter
and the foot sole will click
into position
3
