Toshiba M5 User Manual
Page 152
8-8
User’s Manual
Optional Devices
Installing memory module
There are slots for two memory modules, one over the other. The
procedures are the same for installing either module.
1. Set the computer to boot mode and turn the computer’s power off.
Make sure the Power indicator is off. Refer to the
section in Chapter 3,
.
2. Remove AC adaptor and all cables connected to the computer.
3. Turn the computer upside down and remove the battery pack. Refer to
section in Chapter 6,
, for details.
4. Loosen the screw securing the memory module cover. The screw is
attached to the cover to prevent it from being lost.
5. Slide your fingernail or a thin object under the cover and lift it off.
Removing the memory module cover
6. Align the notch of the memory module with that of the memory slot and
gently insert the module into the slot at about a 45 degree angle before
pressing it down until the latches on either side snap into place.
Seating the memory module
Use a #0 point Phillips screwdriver to remove and fasten the screws. Use
of an incorrect screwdriver can damage the screw heads.
Screw
Memory module cover
Slot A
Slot B
