CLUTCH CLEANING AND MAINTENANCE
After every 5 hour of use, your clutch will need cleaning and lubrication. If
clutch becomes too dirty or has lack of lubrication, the clutch will have a
tendency to stick. This will cause the Mini-Bike to want to take off before
throttle is applied.
To clean and lubricate clutch, follow the instructions below:
1. Make sure engine is turned off and engine is cool before removing clutch
cover.
2. Remove Clutch Cover
3. With compressed air, blow through holes to remove any dust and/or particles.
4. Oil Clutch bearing with a few drops of 30W motor oil.
NOTE: Make sure oil does not get inside clutch itself.
5. Push mini bike forward without starting allowing oil to flow through bearing
surface.
6. Re-install clutch cover.
WARNING
Starting engine with clutch cover removed could be hazardous
Starting engine with clutch cover removed, increases the chance of
getting your person caught in moving components which could result in
severe injury.
Never start Mini Bike with clutch cover removed.
Oil Clutch here
ONLY
Blow out clutch with
compressed air through
large holes
Clutch
Cover
INSPECTION AND MAINTENANCE
