18
ADJUSTMENT OF REAR BRAKE
1. The front brake hand grip should have free operating movement of 5-7mm
(.2-3in.) . Adjust with free play adjustment bolt.
2. To make rear brake pad adjustment, turn rear adjusting bolt clockwise to
loosen and counter clockwise to tighten brake tension.
3. Brake pads should be replaced by a qualified service technician once brake
shoes are worn .
4. Brakes are adjusted by turning in or out the rear brake adjusting bolt
5-7mm free play
(.2-3in.)
Free play adjustment bolt
Rear brake adjusting bolt
INSPECTION AND MAINTENANCE
