27
Installation
Installation on the steering column
1. Install the microphone in the microphone clip.
2. Mount the microphone clip on the steering column.
Adjusting the microphone angle
The microphone angle can be adjusted by moving forward or backward the microphone
clip angle.
Install the microphone clip on the
steering column, keeping it away
from the steering wheel.
Clamps
Use clamps to secure the
lead where necessary
inside the vehicle.
Double-sided tape
Fit the microphone cord in the groove.
Microphone
Microphone clip
