When connecting to separately sold power, When connecting to separately sold power amp, 02 connecting the system – Pioneer AVIC-F9310BT User Manual
Page 10
When connecting to separately sold power amp
The navigation unit
RCA connector
Subwoofer outputs
(SWL, SWR)
To system control terminal of the power amp
(max. 300 mA 12 V DC).
For connection, refer to the wiring and installation
manual separately supplied.
Blue
Rear outputs
(REAR OUTPUT)
Front outputs
(FRONT OUTPUT)
15 cm
15 cm
Engb
10
Section
02
Connecting the system
