Specifications
Amplifier Section
Continuous Power Output (Stereo Mode)
Front ......... 170 W + 170 W (DIN 1 kHz, THD 1 %, 6
Ω)
Continuous Power Output (Surround Mode)
Front ......... 170 W + 170 W (DIN 1 kHz, THD 1 %, 6
Ω)
Center ..................... 170 W (DIN 1 kHz, THD 1 %, 6
Ω)
Surround ..... 170 W + 170 W (DIN 1 kHz, THD 1 %, 6
Ω)
Surr. back .... 170 W + 170 W (DIN 1 kHz, THD 1 %, 6
Ω)
Rated Power Output ................................... 150 W + 150 W
(20 Hz-20 kHz, THD 0.09 %, 6
Ω)
• Above specifications are applicable when the power
supply is 230V.
Audio Section
Input (Sensitivity/Impedance)
PHONO MM ......................................... 4.7 mV/47 k
Ω
LINE ..................................................... 382 mV/47 k
Ω
Phono Overload level (THD.0.1 %, 1kHz)
PHONO MM ..................................................... 120 mV
Frequency Response
PHONO MM .................... 20 Hz to 20,000 Hz ± 0.3 dB
LINE ....................................... 5 Hz to 100,000 Hz dB
Output (Level/Impedance)
LINE ...................................................... 382 mV/2.2 k
Ω
Tone Control
BASS ..................................................... ± 6 dB (100 Hz)
TREBLE ................................................. ± 6 dB (10 kHz)
LOUDNESS ........................... +4/+2 dB (100Hz/10 kHz)
(at volume position -40dB)
Signal-to-Noise Ratio (IHF, short circuited, A network)
PHONO MM ........................................................ 86 dB
LINE ................................................................... 105 dB
Signal-to-Noise Ratio
[DIN (continuous rated power output/50 mW)]
PHONO MM ................................................... 70/68 dB
LINE ................................................................ 93/73 dB
Video Section
Input (Sensitivity) .......................................... 1 Vp-p/75
Ω
Output (Level/Impedance) ............................ 1 Vp-p/75
Ω
Signal-to-Noise Ratio .............................................. 70 dB
Frequency Response ..................... 5 Hz to 10 MHz dB
Component Video Section
Input (Sensitivity) .......................................... 1 Vp-p/75
Ω
Output (Level/Impedance) ............................ 1 Vp-p/75
Ω
Signal-to-Noise Ratio .............................................. 70 dB
Frequency Response ..................... 5 Hz to 40 MHz dB
Miscellaneous
Power Requirements ................. AC 220 - 230 V, 50/60 Hz
Power Consumption ............................................... 660 W
Power Consumption in Standby mode .................. 0.65 W
AC Outlet
SWITCHED ...................................... 100 W (0.4 A) MAX
Dimensions .................... 440 (W)
× 203 (H) × 472 (D) mm
Weight (without package) ...................................... 29.8 kg
Furnished Parts
“AA” IEC LR6 batteries .................................................. 4
Remote Control Unit ........................................................ 1
Touch Pen ........................................................................ 1
Cushion for Remote ......................................................... 4
Microphone ...................................................................... 1
AC power cord ................................................................. 1
U-shaped connectors ....................................................... 2
Operating Instructions .................................................... 1
NOTE:
Specifications and the design are subject to possible
modifications without notice, due to improvements.
+0
–3
+0
–3
+0
–3
Maintenance of External Surfaces
• Use a polishing cloth or dry cloth to wipe off dust and dirt.
• When the surfaces are dirty, wipe with a soft cloth dipped in some neutral cleanser diluted five or six times
with water, and wrung out well, and then wipe again with a dry cloth. Do not use furniture wax or cleaners.
• Never use thinners, benzine, insecticide sprays or other chemicals on or near this unit, since these will
corrode the surfaces.
