12
Application Operations (Continued)
1 Menu bar and menu icons
You can choose the following commands from the application menus.
File
Open
Opens measurement data transferred to the USB device or files stored on the
computer. (see
and
).
Close
Closes a file.
Save
Save measurement data in a file (see
a
a. Choose “Save As” if you which to save already saved data with a different name.
Save As
Receive
With this application, “Receive” cannot be used.
Prints the current individual graph.
b
b. It is not possible to print or preview items that have not been received (items for which there is no
data).
Preview
Displays a preview screen to show how the printed page will appear.
b
Exit
Exits the application.
Display
Graph
The way in which the graphs are displayed can be changed.
Graph 2D
: Displayed in two dimensions.
Graph 3D
: Displayed in three dimensions.
Type
(Reverb display
only)
The reverb characteristics graph display type can be changed.
Each Ch:
All the channels are displayed individually.
The “Each Ch” display type is set when EQ calibration is performed with the
reverberation type set to “ALL CH ADJ”.
Pair Ch:
Composite reverb characteristics for the left and right pairs of the “Front”,
“Surround” and “Surr Back” channels are displayed. The “Pair Ch” display type
is set when EQ calibration is performed with the reverberation type set to
“SYMMETRY” or “FRONT ALIGN”.
Demo
Displays 3D graphs with rotating.
a
a. To finish, reselect and uncheck the box.
