Additional information 12
79
En
Specifications
Amplifier section
Maximum Output Power . . . . . . . . . . . . . . . .170 W/channel
(1 kHz, THD 10.0%, 8 Ω )
Continuous Power Output
Front . . . . . . . . . . . 130 W + 130 W (DIN 1kHz, THD 1%, 8 Ω )
Center . . . . . . . . . . . . . . . . . 130 W (DIN 1kHz, THD 1%, 8 Ω )
Surround . . . . . . . 130 W + 130 W (DIN 1kHz, THD 1%, 8 Ω )
Surround back . . 130 W + 130 W (DIN 1kHz, THD 1%, 8 Ω )
Rated Power Output . . . . . . . . . . . . . . . . . . . . . 100W+100W
(20Hz–20kHz, 0.09%, 8 Ω )
Audio Section
Input (Sensitivity/Impedance)
LINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335 mV/47 k Ω
Frequency Response
LINE. . . . . . . . . . . . . . . . . . . . . .5 Hz to 100,000 Hz dB
Output (Level/Impedance)
REC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335 mV/2.2 k Ω
Tone Control
BASS . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 6 dB (100 Hz)
TREBLE . . . . . . . . . . . . . . . . . . . . . . . . . ± 6 dB (10 kHz)
LOUDNESS. . . . . . . . . . . . . . +4/+2 dB (100Hz/10 kHz)
(at volume position –40dB)
Signal-to-Noise Ratio (IHF, short circuited, A network)
LINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103 dB
Signal-to-Noise Ratio
[DIN (continuous rated power output/50mW]
LINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92/65 dB
Composite Video / S-Video Section
Input (Sensitivity/Impedance) . . . . . . . . . . . . . . 1 Vp-p/75 Ω
Output (Level/Impedance) . . . . . . . . . . . . . . . . . 1 Vp-p/75 Ω
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . 65 dB
Frequency Response . . . . . . . . . . . . . 5 Hz to 10 MHz dB
Component Video Section
Input (Sensitivity/Impedance) . . . . . . . . . . . . . . 1 Vp-p/75 Ω
Output (Level/Impedance) . . . . . . . . . . . . . . . . . 1 Vp-p/75 Ω
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . 65 dB
Frequency Response . . . . . . . . . . . . . 5 Hz to 40 MHz dB
FM Tuner Section
Frequency Range . . . . . . . . . . . . . . . . 87.5 MHz to 108 MHz
Usable Sensitivity . . . . . . Mono: 15.2 dBf, IHF (1.6 µV/75
Ω )
50 dB Quieting Sensitivity . . . . . . . . . . . . . . Mono: 20.2 dBf
Stereo: 41.2 dBf
Sensitivity (DIN) . . . . . . . . . . . . . . Mono: 1.1 µV (S/N 26dB)
Stereo: 50 µV (S/N 46dB)
Signal-to-Noise Ratio . . . . . . . . . . . Mono: 76 dB (at 85 dBf)
Stereo: 72 dB (at 85 dBf)
Signal-to-Noise Ratio (DIN) . . . . . . . . . . . . . . . .Mono: 62 dB
Stereo: 58 dB
Distortion . . . . . . . . . . . . . . . . . . . . . . . Stereo: 0.6% (1 kHz)
Alternate Channel Selectivity . . . . . . . . . . . 70 dB (400 kHz)
Stereo Separation . . . . . . . . . . . . . . . . . . . . . . .40 dB (1 kHz)
Frequency Response . . . . . . . . . . . . 30 Hz to 15 kHz ± 1dB
Antenna Input . . . . . . . . . . . . . . . . . . . . . . 75
Ω unbalanced
AM Tuner Section
Frequency Range . . . . . . 531 kHz to 1,602 kHz (9kHz step)
530 kHz to 1,700 kHz (10kHz step)
Sensitivity (IHF, Loop antenna) . . . . . . . . . . . . . . . 350 µV/m
Selectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 dB
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . 50 dB
Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Loop antenna
Miscellaneous
Power Requirements
. . . . . . . . . . . . . . . AC 110/120–127/220/230–240 V, 50/60 Hz
Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . .470 W
In standby . . . . . . . . . . . . . . . . . . . . . . 0.67 W (220V/50Hz)
Dimensions . . . . . . . . . . . . 420 (W) x 173 (H) x 465 (D) mm
Weight (without package)
VSX-2014i-G . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15.6 kg
VSX-1014-S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15.4 kg
Furnished Parts
Microphone (for Auto MCACC setup) . . . . . . . . . . . . . . 1
Microphone stand. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AA/LR6 dry cell batteries
. . . . . . . . . . . . . . . . . . . . . . . . . . 2
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Antenna adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Flad-bladed converter plug . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Power cord(s):
VSX-1014-S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
VSX-2014i-G (PAL model) . . . . . . . . . . . . . . . . . . . . . . . . . 1
VSX-2014i-G (NTSC model) . . . . . . . . . . . . . . . . . . . . . . . . 2
These operating instructions
Note
• Specifications and the design are subject to possible
modifications without notice, due to improvements.
Cleaning the unit
• Use a polishing cloth or dry cloth to wipe off dust and
dirt.
• When the surface is dirty, wipe with a soft cloth
dipped in some neutral cleanser diluted five or six
times with water, and wrung out well, and then wipe
again with a dry cloth. Do not use furniture wax or
cleansers.
• Never use thinners, benzine, insecticide sprays or
other chemicals on or near this unit, since these will
corrode the surface.
