Connecting up
03
19
En
Connecting antennas
Connect the AM loop antenna and the FM wire antenna
as shown below. To improve reception and sound quality,
connect external antennas (see
Using an external
antenna to improve FM reception
below). Always make
sure that the receiver is switched off and unplugged from
the wall outlet before making or changing any
connections.
Note that the illustration above shows the VSX-2014i-G
however, connection for the VSX-1014-S is the same.
FM wire antenna
Connect the FM wire antenna and fully extend vertically
along a window frame or another suitable place that
gives good reception.
AM loop antenna
Assemble the antenna and connect to the receiver as
shown above. The ground terminal (
) helps reduce
radio noise (it is not an earthing plug). Attach (if
necessary) and face in the direction that gives the best
reception.
• Note that either wire can be inserted into the
respective terminals when connecting.
Antenna snap connectors
Twist the exposed wire strands together and insert into
the hole, then snap the connector shut.
Using an external antenna to improve FM
reception
Use an antenna adapter to connect an external FM
antenna using a coaxial 75
Ω
cable.
Attaching the antenna adapter
Use the antenna adaptor to terminate the coaxial cable
used with an external FM antenna.
1
Cut and strip the coaxial cable to the
specification shown in the diagram.
2
Open the adaptor body by pulling apart the tabs
on either side.
ASSIGNABLE
CD
IN
IN
IN
IN
IN
IN
OUT
OUT
CD-R/
TAPE/MD
VIDEO1
DVR /
VCR
DVD/
LD
TV/
SAT
PRE
OUT
CEN-
TER
CEN-
TER
SUR-
ROUND
SUR-
ROUND
SUR-
ROUND
BACK
(Single)
FRONT
FRONT
SUBW.
SUBW.
MULTI CH IN
MONITOR
MONITOR
VIDEO1
DVR /
VCR
T V /
SAT
DVD/
LD
IN
IN
IN
VIDEO
COMPONENT
ASSIGNABLE
MULTI-
ROOM &
SOURCE
AUDIO
VIDEO
S-VIDEO
RS - 232C
IN
IN
OUT
OUT
OUT
AM
NITOR OUT
12V
TRIGGER
Y
P
R
P
B
P
R
Y
P
B
P
R
1
2
2
IN
1
R
L
R
L
R
L
R
R
L
L
R
R
L
L
PLAY
PLAY
REC
REC
OUT
I R
IN
VIDEO
(DC OUT12V/
100mA MAX)
ASSIGNABLE
S400
S400
IN
(DVD/
LD)
IN
(CD)
DIGITAL
IN (CD-R/
TAPE/MD)
IN
(
4
3
2
1
1
4
AM loop
antenna
FM wire antenna
10mm
AM LOOP
Antenna
adapter
Wire mesh
Pull back
Wire
10–20 mm
5 9
Tabs
