Connecting up
03
20
En
3
Insert the cable as shown, then use a pair of
pliers to wrap the end of the wire around the
binding post. Snip off the excess wire.
4
Use pliers to secure the cable by pinching the
clamps together, as shown.
5
Push the body cover back on.
Using an external antenna to improve AM
reception
Connect a 5–6m length of vinyl-coated wire to the AM
antenna terminal without disconnecting the supplied AM
loop antenna.
For the best possible reception, suspend horizontally
outdoors.
AM LOOP
Outdoor
antenna
Indoor antenna
(vinyl-coated wire)
5–6m
