Connecting the cables (LAN cable and audio cables)
1 Connect the switching hub and DJM-900nexus by LAN cable.
2 Connect the LAN cable and audio cables.
Connect in such a way that the DJ player’s player number and the channel number of the terminals to which the DJ mixer’s audio cables are connected are the same number.
Ex.: When player 2 is connected to [CH2], player 3 is connected to [CH3] and the computer (Mac/Windows) is connected to the DJ mixer
DJM-900nexus
OFF RETURN L
L
L
1 GND 2 HOT
3 COLD
L
R
L L
IN
CH3 CH4
CH1 CH2 R
R
R
R
L
R
R
PHONO
CH 4 CH 3
CD/LINE L
R
PHONO
CH 1
CD/LINE
SIGNAL GND SIGNAL GND
TRS
CD/LINE LINE
MASTER1 MASTER2 REC OUT BOOTH
MIC2 MIDI OUT
DIGITAL
MASTER OUT LINK
L
R
CH 2
CD/LINE LINE
(MONO)
L R (MONO)
SEND
POWER
AC IN
ON
L L L
R
L
R
CH 3
GND SIGN
TRS
CD/LINE LINE
MASTER2 REC OUT BOOTH
L
R
CH 2
CD/LINE LINE
AUDIO OUT R L CONTROL
LINK USB
DIGITAL OUT
POWER
AUDIO OUT R L CONTROL
LINK USB
DIGITAL OUT
POWER
CDJ-2000 CDJ-2000
L R
L R
L R
L R
Checking the connections
Checking the DJ player’s link established by LAN connection (for the CDJ-2000)
Check that the player number indicated on the DJ player’s screen is lit in white.
LINK NG LINK OK
! If the player number indicated on the DJ player’s screen is lit in gray, the link is not established. If there is a DJ player for which the player number is lit in gray, redo the
connection procedure.
! Set the second DJ player on in the same way.
Checking the DJ player’s link established by LAN connection (for the CDJ-900)
Press the DJ player’s [MENU/UTILITY] button for over 1 second to open the UTILITY screen, then check that [CONNECTED] is
displayed for [LINK STATUS].
UTILITY
2
NOT CONNECTED
ON
–
PLAYER No.
LINK STATUS
AUTO STANDBY
MIDI CHANNEL
LINK NG
UTILITY
2
CONNECTED
ON
–
PLAYER No.
LINK STATUS
AUTO STANDBY
MIDI CHANNEL
LINK OK
! If [NOT CONNECTED] is displayed, the link is not established. If there is a DJ player for which [NOT CONNECTED] is displayed, redo the connection procedure.
! Set the second DJ player on in the same way.
Checking that the LAN cable and audio cables are synchronized
Load a music file, then operate the DJ players that are connected by link to play and pause the track repeatedly.
Check that the player number displayed on the DJ player’s screen is the same as the channel number that lights on the DJ mixer’s channel level indicator.
If the numbers are different, fix the connections.
