Mounting with Brackets
Fig. 11
Installing the Remote Sensor
Precaution:
• Do not install on the dashboard where it may be subjected to direct sunlight. High temperatures
may result in damage to the unit.
• Install within the transmission range of the remote control signal.
Stick the supplied double-sided tape to the back of the remote sensor, and attach it to the
center console.
Fig. 12
Double-sided tape
Remote sensor
Truss screw (5
× 8 mm)
Car mat or chassis
Bracket
Tapping screw (6
× 16 mm)
Drill 4 to 4.5 mm diameter holes.
12
ENGLISH
ESPA
Ñ
OL
DEUTSCH
FRAN
Ç
AIS
ITALIANO
NEDERLANDS
