Installation on the steering column
1 Detach the microphone base from the
microphone clip by sliding the microphone
base while pressing the tab.
Microphone Tab
Microphone clip Microphone base
2 Mount the microphone on the steering
column.
Double-sided tape
Install the microphone on the
steering column, keeping it away
from the steering wheel.
Clamps
Use separately sold
clamps to secure the
lead where necessary
inside the vehicle.
Adjusting the microphone angle
The microphone angle can be adjusted.
