ELECTRICAL SPECIFICATIONS*
MODEL WATTS VOLTS 1ø Hz CIRCUIT REQUIRED WIRE
2212 1800 120 50/60 15 AMP (NEMA 5-15R) 2 + ground
2216 3500 120/240 50/60 HARD WIRE TO CIRCUIT BREAKER 3 + ground
2272 1800 120 50/60 15 AMP (NEMA 5-15R) 2 + ground
2216EX 3500 240 50/60 HARD WIRE TO CIRCUIT BREAKER 2 + ground
2274EX 3500 240 50/60 HARD WIRE TO CIRCUIT BREAKER 2 + ground
Canada 1500 watts
TABLE OF CONTENTS
SPECIFICATIONS
Thank You for purchasing this
Bloomfield Industries appliance.
Proper installation, professional
operation and consistent
maintenance of this appliance will
ensure that it gives you the very
best performance and a long,
economical service life.
This manual contains the
information needed to properly
install this appliance, and to use,
care for and maintain or repair the
appliance in a manner which will
ensure its optimum performance.
WARRANTY STATEMENT xi
SPECIFICATIONS 1
FEATURES & OPERATING CONTROLS 2
PRECAUTIONS & GENERAL INFORMATION 3
INSTALLATION INSTRUCTIONS 5
AGENCY APPROVAL INFORMATION 5
OPERATION 6
USERS GUIDE 7
CLEANING INSTRUCTIONS 8
SERVICING INSTRUCTIONS
Operational Adjustments 9
Electrical 10
Plumbing 12
De-liming Heater Tank 14
Diagnostics & Troubleshooting 15
EXPLODED VIEW & PARTS LIST
In-Line Models 16
Step-Up Models 18
WIRING DIAGRAMS
In-Line Models 20
Step-Up Models 21
Inline Export models 22
Step-up Export models 23
DIMENSIONS*
MODEL CONFIGURATION HEIGHT WIDTH OVER ALL DEPTH
2212 3 Warmer In-Line 19 D” (498 mm) 9 h” (235 mm) 22 D” (575 mm)
2216 3 Warmer In-Line 17 D” (498 mm) 9 h” (235 mm) 22 D” (575 mm)
2272 3 Warmer Step-Up 19 D” (498 mm) 16 h” (235 mm) 22 D” (575 mm)
2216EX 3 Warmer In-Line 17 D” (498 mm) 9 h” (235 mm) 22 D” (575 mm)
2274EX 3 Warmer Step-Up 19 D” (498 mm) 16 h” (235 mm) 22 D” (575 mm)
*
for complete information regarding specifications and dimensions, please consult the GLD
(General Layout Data) for the appliance ( 2212 & 2216 GLD p/n 75038, 2272 GLD p/n 75046 ).
