CONTROL BOARD
1 WP3
2 WP2
3 WP1
1 Heater (Line)
2 Inlet (Line)
3 Dump Line
4 Power (Line)
5
6 Dump (Neut)
7 Power (Neut)
8 Heater (Neut)
Line
Load
Gate
Front Warmer
Plate #2
120V
100 Watt
Main Warmer
Plate 120V
100 Watt
Rear Warmer
Plate #3
120V
100 Watt
Outlet
Valve
Inlet
Valve
120 Volt
1500 Watt
Tank Heater
Hi-Limit
White #11
White #11
White #11
White #10
White #10
W
h
ite
#
1
0
W
h
ite
#
1
1
White #12
White #11
Blue #4
Blue #2
Orange #3
Orange #8
Orange #7
Brown #5
Brown #1
Red #6
Red #6
Brown #1
Blue #2
Black #9
Black #9
B
la
c
k
#
9
White #12
White #10
White #11
Triac
WIRING DIAGRAM — STEP-UP MODEL
22
