EN 13

Using the fiber cable adapter

The fiber cable adapter is required when connecting the separately
available UFL-1 underwater flash to the Case using an underwater optical
fiber cable (optional: PTCB-E02).

How to install
1 Attach the optical fiber cable adapter to the diffuser shown in the figure

below.

2 Put the underwater optical fiber cable plug all the way into the optical

fiber cable (optional: PTCB-E02) insertion slot.

Remove the underwater optical fiber cable when you do not use it while
taking picture.

Memo:

RC mode can use only µ TOUGH-8010/STYLUS TOUGH-8010.
When UFL-2 is used, set camera and UFL-2 to RC mode.
For details, see the instruction manual of digital camera and UFL-2.
