Names of parts
119
10
Mi
scel
la
ne
ous
OK/MENU button ( Z)
g P. 10, 11
OK/MENU button ( Z)
g P. 10, 11
Monitor
g P. 20, 63 106
Battery compartment
cover
g P. 57, 83, 89
Tripod socket
Viewfinder
g P. 20
POWER switch g P. 8
Self-timer button ( Y)
g P. 10, 42
Macro button ( &) g P. 10, 32
Flash mode button ( #)
g P. 10, 34
Shooting mode button ( -Virtual Dial) g P. 10, 28
QUICK VIEW button
g P. 8
Printer connector
POWER switch
Playback mode
g P. 9
Shooting mode
g P. 8
Lock button g P. 8
Arrow pad
(
acbd)
g P. 10
Buttons on the arrow pad have their respective functions. They are also used
as direction buttons.
a ,c ,b and d indicate which button to be pressed.
