ENGLISH

Carefully slide the unit into the sleeve until it locks

into place.

Press

RESET

(30) with a pen or other pointed object

after all connections are made.

Attach the front panel (A) as described under “Attach

Front Panel”.

CAUTION

Cable damage possible!

To avoid cable damage observe the cables when slid-

►

ing the unit into the sleeve.

Attach the frame.

Remove Unit

Follow these instructions to remove the unit:

Remove the frame.

Insert left and right installation keys in the slots left

and right (the claws are now bent back).

Slide the unit out of the sleeve.

NOTE

Unevenness of the casing can cause the claws to

►

lock. Unlock the claws with the installation keys, if

necessary.

Toyota or Nissan Installation

NOTE

Sleeve, frame and mounting strip are not needed.

►

Use the threads on the side of the casing (A) to mount the

unit on the vehicle bracket (supplied with your car). The

holes are marked with T (for Toyota) and N (for Nissan).

Loosen the mounting screws for the hooks left and

right at the front of the unit and remove the hooks.

Mount the brackets (B) with screws on the unit (D).

Connect External Audio Device

Connect line out of the external audio device to

AUX

(16) jack on the front panel.

Select playback mode for external device by repeatedly

pressing

PAIR/MOD

(4) until

AUX

is displayed.

Fit steering wheel mount for remote control

You can mount the remote control onto the inside of the

steering wheel. Follow the steps below:

1 Rubber strap

2 Mounting bracket

3 Mounting bracket cover

4 Screws

5 Remote control

Use a Philips head screwdriver to loosen the screws (4),

in order to disassemble the steering wheel mount into

the parts shown above (1-4).

Place the rubber strap around the steering wheel.

When doing so, select the corresponding pre-punched

holes to fasten the mount

securely

to the steering

wheel.

Place the cover (3) over the mounting bracket (2). Then

tighten the screws (4) again.

Insert battery into remote control

NOTE

Before using the remote control for the first time,

►

you must insert the supplied battery to make the

remote control ready for use

The life of the supplied batteries may be shortened

►

due to storage conditions.

Open the battery compartment (17) of the remote

control.
