AEG Charger LK 1204 - Manual (Page 26)

26
Charging phases
Voltage “V”
14.2
14.7
13.5
12
10.5
2.5 - 8A
Charging device LK 1204
1.8 - 2.1A 1.2 - 1.4A 0.7- 0.9A
<1A
13.9 - 14.2(v)
14.2 - 14.7(v)
13.5- 13.7(v)
2.3 - 12.5(v)
10.5- 12.3(v)
Time "t"
Charging current “A”
Voltage “V”
14.2
14.7
13.5
12
10.5
3.0 - 3.5A
1.8 - 2.3A
Charging device LK 1206
1.2 - 1.4A 0.7 - 0.9A <1A
13.7(v)
14.2 - 14.7(v)
13.5- 14.2(v)
13.0- 13.5(v)
10.5- 12.5(v)
Time "t"
Charging current “A”
