Hardware Description

Dimensions

RNS5/8 Industrial 5-port/8-port Ethernet Rail Switch dimensions (W x H x D) are

54mm x 135mm x 105mm

Front Panel

The Front Panel of the RNS5 Industrial 5-port Ethernet Rail Switch is shown in

Figure A.

LED Indicators

UTP Ports

Figure A. Front Panel of the RNS5 Industrial 5-port Ethernet Rail Switch

3
