Mounting Installation
DIN-Rail Mounting
The DIN-Rail clip is already attached to the RNS5/8 when packaged. If the
DIN-Rail clip is not screwed on the RNS5/8, follow the instructions and the figure
below to attach the DIN-Rail clip to the RNS5/8.
Rear Panel of the RNS5/8
DIN-Rail Clip
1. Use the screws to attach the DIN-Rail clip to the rear
panel of the RNS5/8.
2. To remove the DIN-Rail clip, reverse step 1.
