Programming the Unimode 200 EIA-485 In Conduit
28 Document 50520 Rev D 7/25/00 P/N 50520:D
Section 6:
Programming the Unimode 200
The Unimode 200 must be programmed to allow use of the
ADT-LCD40 Series Annunciators. In order to program the Unimode
200, make certain the main circuit board 'Write Protect' switch (SW1) is
in the down position and then press the ENTER key on the panel key-
pad. After pressing ENTER, the screen shown below is displayed:
1 = PROGRAMMING
2=RD.STATUS 3=AC/BAT
To enter the Programming Mode, press '1'. The display will read:
KEY PASSWORD, ENTER
Enter the Level 1 password. The following screen will appear:
0=CLR 1=AUTO 2=POINT
3=SYS 4=PWORD 5=LOAD
Press '3' to enter System Edit. The system edit screen may appear as
shown (note that previous programming may have altered some N or No
designations to Y or Yes):
V=N I=N A=N P=N C=N
A/U=N L/P=N S=4 R=4
Use the left and right arrow keys to move to the L/P option. Once at the
L/P option, to enable the ADT-LCD40 Series Annunciator option, use
the up and down arrow keys to scroll to the L (for ADT-LCD40 Series
Annunciator) choice. The ADT-LCD40 Series can now communicate
with the Unimode 200.
To leave Programming Mode, press the Backspace (left arrow) key
repeatedly until Program Mode is exited.
