Alloy Computer Products NS-24T01FS User Manual
Page 31
25
1
2
3
4
VLAN1
5
2
3
4
VLAN2
X
Figure 15. There is no connection between PC1 and PC5
Using VLAN, it can divide the Switch into many independent
small switches. For example, in Figure 16, the Switch has been
divided into four VLAN groups. All VLAN groups are
independent and there’s no link between each VLAN group. The
Switch can be regarded as four smaller switches.
X
X
VLAN3
VLAN2
VLAN1
Figure 16. Dividing the Switch into two smaller switches
