11
automatically and may be turned on without having any or all
LAN segment cables connected.
I
DENTIFYING
E
XTERNAL
C
OMPONENTS
This chapter describes the front panel, rear panel, and LED
indicators of the Switch.
Front Panel
The figure below shows the front panels of the Switch.
Figure 3. Front panel of 24-port 10/100Mbps Fast Ethernet
Switch
¾ LED Indicator
