Page 19: Figure 5. led indicators of the switch, Power: power indicator
13
U
NDERSTANDING
LED
I
NDICATORS
The front panel LEDs provides instant status feedback, and, helps
monitor and troubleshoot when needed.
1
POWER
SYSTEM
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
24-Port 10/100Mbps Ethernet Smart Switch
Link/ACT
FDX
17
18
19
20
21
22
23
24
FX
Figure 5. LED indicators of the Switch
Power and System LEDs
¾
POWER: Power Indicator
On
: When the Power LED lights on, the Switch is receiving
power.
