Aquatic RESTORATION 1 AIY6017TO - Manual

147
SPECIFICATIONS:
The manufacturer accepts a 1/4” variance. There are variations on each tub and specifications are subject to change as we improve upon our product as required. The dimensions needed for site preparation
and structure building should be measured from the tub; Aquatic Industries, Inc. assumes no responsibility for preparatory work.
www.aquaticwhirlpools.com 800.555.5324
January 2008
Rough-In Plumbing
Measurements
rESTOrATION SErIES
Model # AIY6017to
rESTOrATION 1
GeneRal SPecIfIcatIonS:
Tub Size 60” x 31 1/2” x 30 1/4”
152 cm x 80 cm x 77 cm
Bathing Well 40” long
16” wide
16 1/2” interior depth
Shipping Weight 194 lbs. / 88 kg
Tub Weight Filled 432 lbs. / 196 kg
Tub Only Weight 90 lbs. / 41 kg
Gallons to Overflow 41 gal. / 155 L
aquatic Quality features:
- Slip Resistant Floor
- Deep Bathing Well
- Claw Feet Available in Chrome, Polished Brass, Satin Nickel,
Polished Nickel, Oil Rubbed Bronze and White
- Thick, Durable Acrylic Surface
- Available in White Only
Ul & IaPMo listed
limited lifetime Warranty
StandaRd eQUIPMent:
29”
30 1/4”
22 1/2”
23 1/2”
20 3/4”
oPtIonal eQUIPMent:
• Comfort Pillow - Oval or Rectangle
(White, Biscuit or Black)
•
Freestanding Waste and Overflow
- Chrome, Polished Brass, Polished Nickel,
Satin Nickel, Oil Rubbed Bronze or White
16”
40”
60”
31 1/2”
fax-on-demand
document #1261
2 1/4”
11”
