Exhibit 3-5 fc-41xs adapter, Exhibit 3-6 fc-21ps adapter, Exhibit 3-7 fc-24xl advanced adapter – ATTO Technology Celerity FC host adapters FC-44ES 4-Gb User Manual
Page 18
13 ATTO Technology Inc. Celerity FC Host Adapters Installation and Operation Manual
Exhibit 3-5 FC-41XS Adapter
Exhibit 3-6 FC-21PS Adapter
Exhibit 3-7 FC-24XL Advanced Adapter
SFP LC optical
connector
If LED lit, the storage
adapter is online
SFP LC optical
connectors
If LED lit, adapter is online
FC24XL
If LED lit, indicates
the channel is using
2-Gb FC
SFF duplex LC
optical connector
If LED lit, the storage
adapter is online
If LED lit, indicates the
channel is using 2-Gb FC
