Removal steps of the audio-card cable
1
1
2
When installing: Ensure that the cable is attached firmly to the system board and the audio card.
1070 Audio card
For access, remove this FRU:
•
“1010 Back cover assembly” on page 41
• “1060 Audio-card cable” on page 45
Removal steps of the audio card
2
1
1
Step Screw (quantity) Color Torque
1 M1.6 × 2.5 mm, flat-head, nylon-coated (2) Black 0.098 Nm
(1.00 kgf-cm)
1080 Touch-sensor-card support bracket
For access, remove this FRU:
•
“1010 Back cover assembly” on page 41
• “1060 Audio-card cable” on page 45
• “1070 Audio card” on page 46
46 Hardware Maintenance Manual
