Lenovo ZhaoYang K2450 Hardware Maintenance Manual
40
Figure 2. Removal steps of battery pack (continued)
Unplug the battery connector in the direction shown by arrow first, then
remove three screws .
Remove the battery in the direction shown by arrow .
Step Screw (quantity) Color Torque
M2 × 5 mm, flat-head, nylok-coated (3) Black 1.85+/-0.15 kgfcm
a
b
b
b
b a
c
c
c
